UHMWPE Hard Large Board Forming UHMW Plastic Sheet

We can make different UHMWPE Sheet according to different application .Like anti-UV resistant anti-static and with other characters , Best quality with good surface and color make our UHMWPE sheet more and more popular all over the world.

Availability:



Inquire Add to Basket

Product Description

UHMW-PE Technical Data:

1.Mechanical Properties
Item	Unit	Method	Index
Density	g/cm3	ASTM1505	0.94
Tensile Strength	MPa	D638	42
Tensile Strain at Break	%	D638	350
Charpy Impact Strength (Notched)	Kj/m2	D256	≥100
2.Thermal Properties
Item	Unit	Method	Index
Melting Point	℃	ASTMD2117	136
Vicat Softening Temperature	℃	ASTMD1512	134
Coefficient of Liner Thermal Expansion	10-4/℃	ASTMD648	1.5
Temperature of Deflection	℃	ASTMD648	90
3.Electrical Properties
Item	Unit	Method	Index
Volume Resistivity	Ω.cm	ASTMD257	1017
Surface Resistivity	Ω	ASTMD257	1013
Dielectric Strength	kV/mm	ASTMD149	900
Dielectric Coefficient	106Hz	ASTMD150	2.3
4.Low Temperature Resistance:The brittle temperature is -140C when the molecular weight -0.5 million. UHMW-PE even has mechanical strength under-269 if used with liquid nitrogen or liquid helium.

Properties of UHMW Polyethylene Sheet:

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications

--Easy Reprocessed plastic ground protection mat

-Creats an instant roadway over virtually any type of terrain – mud, sand, marshy, uneven or soft terrain

- Extremely durable to withstand vehicle weights up to 80 tons

- Tested in extremes of hot and cold climates

Product Description:

Size of UHMW Polyethylene Sheet :

2000X1000X(10-100)MM 2200X2000X(10-100)MM 2300X1200X(10-150)MM 2500X1300X(10-150)MM 3000X1500X(10-200)MM 3050X1220X(10-60)MM 4500X2000X(10-100)MM 4700X1200X(10-150)MM 5000X1300X(10-150)MM

Color of UHMW Polyethylene Sheet :virgin ,Black ,Green ,Yellow , Blue ,Orange and other color
